Weichai Diesel Engine 32inch Cutter Suction Dredger with Maximum Dredging Depth 18m

Model NO. : QHCSD-295

Slot Type : CTS

Customized : Customized

Condition : New

Warranty : 1 Year

After-sales Service : Lifelong

Hull Size : 35*10.2*2.7m

Output Pipe Diameter : 800mm

Maximum Dredging Depth : 18m

Water Flow : 9000m3

Capacity : 1350m3-1800m3

Maximum Discharge Distance : 1500m

Cutter Head Diameter : 2400mm

Cutter Power : 450kw

Total Weight : 380ton

Main Engine Power : 2427kw

Auxiliary Engine Power : 736kw

Diesel Engine Brand : Cumins

Total Fuel Consumption : 547L

Hydraulic Control System : Rexroth /Ward

Electric System : PLC and ABB

Transport Package : Canvas

Specification : 32inch water flow 9000m3

Trademark : Set Sail

Origin : China

HS Code : 8905100000

Supply Ability : 2500set /Year

Package Size : 4600.00cm * 1002.00cm * 270.00cm

Package Gross Weight : 447000.000kg

Type : Cutter Suction Dredger

Power Type : Diesel

Cyclone Type : Hydrocyclone

Samples : US$ 3000/Set 1 Set(Min.Order) |

Customization : Available | Customized Request

Shipping Cost : about shipping cost and estimated delivery time.

: Initial Payment Full Payment

Currency : US$

Return&refunds : You can apply for a refund up to 30 days after receipt of the products.

Place of Origin : China

Certification : ISO 9000, ISO 14001，ISO 20000, ISO 14064, LEED, ISO 10012, ISO 17025

MOQ : 1 set

Price : Negotiable

Packaging Details : Container

Delivery Time : Peak Season Lead Time: 1-3 months, Off Season Lead Time: one month

Payment Terms : LC, T/T, D/P, PayPal, Western Union, Small-amount payment, Money Gram, Cash

Contact Now

Weichai Brand Diesel Engine 32inch Cutter Suction Dredger for sand

1. Company profile:

Qingzhou Set Sail Dredging Machinery Equipment Co., Ltd .our factory is one of China leading company of sand & gold& diamond mining equipments. has more than 25 years' experience in designing.producing.selling cutter suction dredger. jet suction dredger. bucket chain dredger. diamond/gold dredgers. sand washing plant. gold washing plant. sand washing & screening machinery. sand transport barge.work boat and so on. Successful series of products have won the recognization and approval of general administration of Quality Supervision. Now our company's products are widely exported and used in the Aisa.Afrrica.South America.Middle Easr and other regions.
As for more information about our company and products,Please serach https://dredgerfactory.en.made-in-china.com

Weichai Diesel Engine 32inch Cutter Suction Dredger with Maximum Dredging Depth 18m

2. Cutter suction dredger introduce :

Cutter Suction Dredgers are of the highest possible quality. ensuring a long lifetime with a minimum of maintenance. The maxmum capacity of 32 inch dredger can reach to from 1800-2700 m3 water flow can go up to 9000 m³/h, and digging depth to 1-25 meters, discharge distance to 200-3000 meters.

3. 32 inch cutter suction dredger parameter:

Total length	46m
Hull size	3510.22.7m
Discharge pipe diameter	800mm
Water flow	9000m3/h
solid capacity	1350m3-1800m3
Discharge distance	1500m
Cutter head diameter	2400mm
Cutter head power	450kw
Draught	1.6m
Displacement	477ton
Total weight	380ton
Main engine power	Cumins 2427kw
Auxiliary engine power	Cumins 736kw
Total fuel consumption	547 litre
Hydraulic control system	Rexroth
Electric control system	Siemens PLC

4. Product advantage :

1	Relable and high efficiency-improtant device is international brand
2	After sales service -engineer in the working site for installation and training ,24/7 technical support .
3	Provide free spare part for a year. then cost to offer service and spare part
4	Can dismantled and easy transportation

5.our service :

Set Sail Services intends to provide added value to a Set Sail vessel. whether this involves a single service or
a complete package such as integrated logistics support or a long-term service agreement.

6. Features:

1	Wide range of use applications
2	High efficiency. large output. long pump distance.low fuel consumption
3	Rexroth. Vickers full hydraulic control
4	Siemens PLC is easy to operate
5	Engine choice from Weichai. Cumins. and more.
6	Equipped with Australian technology dredge pump
7	The modular design enables fast assembly with HID seniors engineers
8	Dredger components available in factories to allow short delivery times
9	Control the working process of dredging and pumping. delivering dredged materials. lower cost.
10	Follow manufacture guideline: CCS-ZC standard
11	CE ISO certificates acquired to prove high quality
12	Western Dredge brand parts. easy to find globally
13	Can choose reliable Chinese brand parts to lower costs
14	Gain access to our sales team. design team, manufacture team 24/7

7. FAQ:

1.Are your trading company or factory ?

We are factory factory name is Set sail factory of more than 20 years

2. How is your price of cutter suction dredger ?
First we can offer the precise and professional design. Price must be match the quality

3. How is your manufacture period ?
Normal we have in stock on hot sale cutter suction dredger size . others we can finished in the 1-3 hours

4. How is your grouped equipment on your cutter suction dredger ?
Abroad Famous brand diesel engine brand slurry pump PLC system Hydraulic control system brand etc on our cutter suction dredger we can according to the requirement of customer to customized

5.How is your packaging and transportation ?
All cutter suction dredger transport by bulk we use the specially protection material to packaging. The fist layer use the film to pack the main pontoon the other equipment pack into the pontoon each the equipment is separated by the vacuum bag to protect the undamaged.

6. How is your payment system?
Our factory support T/T L/C etc.

7. How is your service?
Before sign contract we can send the engineer to the working site the research . then according to the requirements to make the design . professional engineer track throughout Cutter suction dredger is finished our factory will send the installation team to the abroad To help installation and training local worker .until cutter suction dredger can normal working

8.why choose Set Sail ?
1. Simple, rapid assembly and dismantling

2. Spare parts and floating pipe available

3. Transportable by road, rail or sea

4. Reliable hydraulic system

5. Fresh water engine cooling system

6. Low fuel consumption

7. Easy to operate

8. Good after-sales service

9. Certification:

10. other information : Weichai Diesel Engine 32inch Cutter Suction Dredger with Maximum Dredging Depth 18m
